3D Printed Mini Long-range FPV Platform & LOS Trainer!

Ranger V3 is a next-generation FPV trainer built for beginners and explorers alike. Unlike many planes, it requires no carbon rods and comes with a fully 3D printed landing gear system, making it one of the easiest and most affordable 3D printed planes to build. Strong, stable, and lightweight, Ranger V3 is your perfect entry into the world of RC and FPV flying.

📦 Included in your Complete Kit

• Airframe Kit, complete 3D printed airframe package, ready to assemble and form the full aircraft structure.
  • 3D printed body parts (PLA) – Main airframe components, ready to assemble
  • 3D printed hardware (PETG) – Motor mount, control horns, and other brackets
  • Flex Parts (TPU) – Hinges, straps, wheels, and other necessary flexible parts
  • Pushrods – Steel wire rods for precise control linkage
  • Hardware pack – Screws, rods, wires, and all small essentials for assembly
  • Lipo strap (Velcro belt) – Secure battery mounting solution
  • Craft mat – Protects your table from glue during assembly
  • Nitrile gloves – Keep your hands clean and safe while working with glue
  • Special gifts – Surprise extras included in every kit 🎁
• Power Pack, Eco Series setup including brushless motor, analog ESC compatible with 2S to 3S batteries, propeller, and required micro servos. All components are selected for compatibility and easy installation.
  • 2205 2300kv Motor – Matched to the size and flight style of your model
  • 30A ESC – Smooth and efficient power delivery with XT60 compatibility
  • 5040 Propeller – Optimized for thrust and efficiency
  • 9g Servos (4x) – Selected high-quality 9 g class for precise control
• Radio and Receiver, Flysky FS i6 2.4GHz 6 channel transmitter with AFHDS 2A protocol, LCD screen for clear setup and monitoring, multiple model memory, plus a compatible receiver included for reliable control.
• Battery, Craycle 3S 11.1V Li ion pack, 2800 mAh capacity with 25A continuous discharge, XT60 connector and balance lead, optimized for lightweight and efficient flight.
• Charger, iMAXRC B3 Pro compact balance charger, compatible with 2S and 3S batteries (7.4V and 11.1V), 100 to 240V AC input, simple and safe plug and charge operation.

General Specifications

• Length: 600 mm (23.6 inches)
• Wingspan: 800 mm (31.5 inches)
• Print Weight: 309 g (10.9 oz)
• Flying Weight: 570 g (20.11 oz)
• Wing Area: 11.8 dm²
• Wing Loading: 48.3 g/dm²
• Airfoil: NACA 2412
• Material:
  • Regular PLA: Body
  • PetG: Electronic Brackets
  • TPU: Hinges, wheels

🚤 Float Option Available

Extend your Ranger V3’s capabilities with optional 3D printed floats, perfectly designed for seamless water takeoffs and landings. This add-on transforms your plane into an amphibious trainer, allowing you to fly from lakes or ponds without compromising performance. Buy floats!

⚡ Stronger and Smarter Design with V3

• Nose-diving problem solved
• 100 g lighter than V2 with a larger wing area
• New dihedral wings for added stability
• Optimized aileron, elevator, and rudder controls
• Durable 3D printed landing gear and optional bush wheels
• Float-ready for water takeoffs and landings

🎥 FPV Ready

Designed with a dedicated canopy and optimized airflow, Ranger V3 supports both analog and digital FPV systems. Whether you’re practicing line-of-sight or stepping into immersive FPV, Ranger is ready to adapt to your flying style.

Why Choose Ranger V3

Ranger V3 is designed to be the most accessible 3D printed FPV trainer. With no carbon rods, fully printed landing gear, and stable flight characteristics, it’s the perfect model for beginners—and still exciting for advanced pilots who want a reliable FPV explorer.

Buy the Ranger V3 today and start flying with a trainer plane that grows with your skills.
